Product Details:
Payment & Shipping Terms:
|
| NAME: | HEAVY DUTY PIPE THREADING MACHINE | MODEL: | STT100F |
|---|---|---|---|
| CAPACITY: | 1/2''-4'' | DIE HEAD: | 1/2''-2'', 2-1/2''-4'' Manual Retract Or Auto Retract |
| DIE: | 1/2-3/4'', 1''-2'', 2 1/2''-4'' BSPT/NPT, OR METRIC DIES | FEATUER: | HIGH EFFICIENCY |
| POWER: | 1500W | PLUG: | AS YOUR REQUEST |
| VOLTAGE AND FREQUENCY: | AS YOUR REQUEST | USAGE: | Fire Fighting Pipeline Building |
Pipe threading machine is applicable in cutting,carving thread and inner hole chamfering varieties inches tubes for purpose of water.electric and gas.
Features
Voltage:380V/220V/110V (or Custom)
Whole aluminium casing body, brand-new, beautiful appearance.
1500W copper induction motor is driven seperately to avoid burning by oil.
Independent gearbox structure, equipped alloy steel gear, oil lubrication, durable use life.
Three-lever gear design, makes transmission more easy and accurate.
Cast steel shifting structure stronger without cracking risk
Parameter
| Product Name | 1500w 1/2-4" portable electric pipe threader pipe threading machine |
| Rotational speed of main shaft | 38/22/12 r/min |
| Model of die head | 100F Multi-Functional Die Head(1/2-2") |
| Swift Open Type Copying Die Head(2(1/2)-4") | |
| Scope of application | 1/2-4" |
| Power of motor: | 1500W |
| Gross net weight | 155kg/135kg |
| Packing dimension | 900mm*640mm*680mm |
| Item | threading machine |
| Key word | powerful pipe threading machine |
FAQ
1. How to get a accurate quotation from us?
Provide us the detail of the material such as metal thickness and width.
2. What’s the shipping cost from China to your country?
We can send machine to your port or door address by sea or airplane. Please kindly tell us your nearest port or address with postcode.We have reliable shipping agent to insure the safe, convenient and timely delivery.
3. Payment terms, MOQ, warranty, FOB?
Payment terms: 30% TT paid in advance, the balance of 70% before the shipment.
Minimum order quantity: 1 set.
FOB :Shanghai/Ningbo
Delivery time :7 days after receipt of formal order and 30% deposit.
Warranty:12 months.
4. What’s the package?
Fumigation-free plywood case.
5. What about commissioning service?
We can offer commissioning service, the buyer need to afford plane tickets.
6. What’s policy for guarantee and broken parts?
Warranty period of equipment lasts a year, during which the broken parts and spares caused by quality can be offered free.
7.Any question, call us or send email, we will try our best to satisfy you.
